Weishaupt WG20 1-C Z-LN Series User Manual

Installation and operating instruction
Gas burner WG20…/1-C Z-LN
11 Technical documentation
83054602 1/2020-01 La
74-96
11 Technical documentation
11.1 Wiring diagram
For special version observe wiring diagram supplied.
T1
T2
S3
B4
X6
P
P
F7
F2
P6
P11
B15
L PE N
S1
L
PE
N
P
B10
X3:11
1
B5
T6
T7
T8
X7
B16
P
X4:1
M
M20
2
X5:1
S3
4
F1
W-FM 10
K1
K3
5
1
4
6
11
3
12
13
X6
X7
X4:1
X3:
F7
W-FM 10
X5:1
B10 Air pressure switch
B15 Temperature or pressure regulator
B16 Temperature or pressure regulator full load
F1 External fuse (max 16 AB)
F2 Temperature or pressure limiter
F7 Internal unit fuse (T6.3H, IEC 127-2/5)
M20 Air damper actuator
P6 Control lamp lockout (optional)
P11 Control lamp operation (optional)
S1 Operating switch
S3 Remote reset (optional)
1 Bridge for single stage operation
2 Bus interface (optional)
