12986372820 Chariot 3 iExtract 26 Duo

Battery Exchange - 3

REF PART NO. QTY DESCRIPTION

SERIAL NO.

FROM

NOTES

1 86360040 1 BATTERY STOP, LEFT

2 86360050 1 BATTERY STOP, RIGHT

3 86319670 2 SLEEVE, BEARING

4 86363760 2 PLATE, SHIM .030" THIC

5 86010670 2 WASHER 5/16 FLAT SS

6 86007020 2 SCREW, 5/16-18 X 1.25 HHCS SS NP

7 86279190 2 WASHER, 10 FLT TYPEB FLT ZNPLT

8 86360090 2 STANDOFF, RND, 3/8 OD, 10-32 X3/8

9 86298200 2 STANDOFF, .43 OD, 1/4-20 X.75 L

10 86360060 1 BRKT, SPING MOUNT, LT

11 86360070 1 BRKT, SPRING MOUNT, RT

12 86254890 2 SPRING EXT, .50 D X 4.0 L

13 86010670 2 WASHER 5/16 FLAT SS

14 86270830 2 NUT, 5/16-18 HEX NYLOCK S

15 86273780 2 SCREW, 1/4-20 X .75 HHCS SS NP
