46
Maintenance
Transporting
Pushing Machine
The machine may be pushed for short distances at
speeds not to exceed 5 mph. Be careful to avoid
damaging machine. The machine may be pushed by
hand from the rear.
NOTE: To avoid damage caused by regenerative
voltage, disconnect traction motor before towing or
pushing machine.
Machine Tie-Downs
There are four tie down points, two on the front wheel
guards, and two on the rear axle located on either side
of the foot box.
Preparation for Loading/Unloading Trailer
Scrub head must be in the up position before loading.
When transporting the machine on a trailer or in a truck,
in addition to using tie-downs, be sure to set the parking
brake, and block the tires to prevent the machine from
rolling
86372820 Chariot 3 iExtract 26 Duo
Tie down point
Tie down point
Wheel Guards
Rear Axle
(Both sides)
(Both sides)
