5586372820 Chariot 3 iExtract 26 Duo
Brush Deck 2
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86372830 1 CLIP, MANIFOLD
2 86372680 1 BRACKET, SOLENOID
3 86372670 1 COVER SOLENOID
4 86371680 1 BRACKET, SHAFT COVER
5 86371580 1 BRACKET, HOSE
6 86370480 1 SLEEVE, 17 SH 4.09”, HYTREL, GRN
7 86370470 1 HUB, COUPLING, 18ES 1/2” D-BORE
8 86354990 2 CLAMP, .75 DIA, FLEX LOOP, NYLON
9 86340490 2 BRKT, MOTOR MOUNT
10 86275470 2 SCREW, 10-32 X 5/8 PPHMS SS
11 86273750 6 SCREW, 1/4-20 X 5/8 HHCS SS NP
12 86006590 2 SCREW, 10-32 X .5 PHPNHMS SS NP
13 86270990 2 NUT, 10-32 HEX NYLOCK SS
14 86270830 16 NUT, 5/16-18 HEX NYLOCK SS
15 86010670 18 WASHER, 5/16 FLAT SS
16 86010630 6 WASHER, 1/4 ID X 5/8 OD SS
17 86222130 1 MOTOR, 36VDC
18 86373220 1 BRACKET, DECK BALANCE
19 86173340 6 WASHER, SPLIT LOCK, 1/4, SS
20 86173330 6 WASHER, M5, FLAT, ISO7093, SS
21 86276220 1 SCREW, 8-32 X .375 HHMS SS
22 86278990 1 WASHER, 8 X .375 X .032 FLT SS
23 86134850 1 WASHER,SPRNG LK,M4,DIN127B,SST
