39
Maintenance
Do not use a pressure washer to clean around the
brush motors. Use tap pressure only.
Brush Motor Carbon Brush Replacement
1. Scribe alignment mark on motor barrel to motor cap.
Remove two bolts.
2. Remove end cap from motor.
NOTE: NOTE: Motors contain two wave washers in
cap. Do not lose these.
3. Release brush from spring tension. Remove screw
connecting brush wire lead to brush holder. Clean
brush holder to ensure free movement.
4. Retract spring and install new brush. Install
connector screw and lead.
5. When all new brushes are installed. Place all in
retracted position, held into brush holder by spring
tension.
6. Carefully place end cap onto bearing on motor shaft.
NOTE: NOTE: Use care to ensure wave washer
alignment.
7. With end cap in partially installed position, release all
brushes to contact position with motor commutator.
NOTE: NOTE: Failure to ensure all brushes are
released will result in motor failure.
8. Reset end cap and realign with scribe marks on
motor barrel. Reinstall the two attach bolts from cap
into base.
9. Maintain alignment between motor barrel base and
cap.
86372820 Chariot 3 iExtract 26 Duo
