13186372820 Chariot 3 iExtract 26 Duo
Pump - Off-Aisle - For Models 10061670 & 10061680 (4*)
* SEE SERIAL NUMBER PAGE
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86391430 2 WASHER, .683 X 1.35 X .06 SS
2 86391420 1 BRACKET, MOUNT, PUMP
3 86391410 1 PLENUM, VACUUM
4 86371850 1 COUPLING, QD, 3/8 NPT
5 86276070 3 SCR, 5/16-18 X 3/4 CARRIAGE SS
6 86270990 4 NUT, 10-32 HEX NYLOCK SS
7 86368240 3 NUT, 5/16-18, FLGNYLOCK, SS
8 86264940 6 CABLE TIE, 11.38" UL/CSA
9 86006100 1 PUMP ASM, 36V ACCESSORY
10 86257450 2 TERMINAL, 1060-16-0122
INCLUDED W/
PUMP ASM
11 86233760 1 CONNECTOR, DT04-2P
INCLUDED W/
PUMP ASM
12 86246730 1 LOCK, W2P
INCLUDED W/
PUMP ASM
13 86247720 1 NIPPLE, 1/8 CLOSE
14 86200820 1 NIPPLE, 1/8
15 86197760 1 TEE, 1/4 STREET
16 86197420 1 ELBOW, 3/8NPT STREET
17 86197400 1 ELBOW, 1/8NPT STREET
18 86197390 1 ELBOW, 1/4NPT 45D STREET
19 86197300 1 BUSHING, 1/8 FPT X 1/4 MPT HEX
20 86197290 1 BUSHING, 3/8 MPT X 1/4 FPT HEX
21 86279020 2 WASHER, #6 LOCK EXT STAR SS NOT SHOWN
22 86010650 4 WASHER, #10 X 9/16 OD
23 86010630 2 WASHER 1/4 ID X 5/8 OD SS
24 86005810 2 NUT 1/4-20 HEX NYLOCK SS
25 86005590 1 NIPPLE 1/4 CLOSE
26 86005580 1 NIPPLE 1/4 FPT QD
27 86251410 1 RELAY, 15A 36V MINI NOT SHOWN
28 86255900 2 STANDOFF, 6-32 X 5/8 HEX NYL NOT SHOWN
29 86264920 1 CABLE TIE, 7" UL/CSA NOT SHOWN
30 86264930 3 CABLE TIE, 3.5" UL/CSA NOT SHOWN
31 86292780 1 SWITCH, MICRO NOT SHOWN
32 86295200 1 ASM, BUTTON, BLACK, W/BEZEL NOT SHOWN
33 86391490 2 LABEL, OFF-AISLE, iEXTRACT 26 NOT SHOWN
34 86391730 1
HARNESS, RELAY/SWITCH, O-A,
iEXTRACT26
NOT SHOWN
35 86391740 1 HARNESS, PUMP, OFF-AISLE, iEXTRACT26 NOT SHOWN
- 86392110 1 KIT, PUMP, OFF-AISLE (4*) COMPLETE
