Winterhalter PT 500 User Manual

Technical data
26
19 Technical data
Voltage
see rating plate
Total connection value
Fuse
Minimum flow pressure
 14.1
Maximum inlet pressure
Water inlet temperature
Dimensions
20 Emissions
Noise
Workplace-related emission sound pressure level Leq < 63 dB(A)
Measurement uncertainty: K(pA): 4 dB
Exhaust air
Adhere to the VDI Guideline 2052 when designing the ventilation system.
21 Disposal
Contact your dealer so that the materials in the machine can be reused or disposed in accordance with local
legislation.
*) Standard working height is 850 mm which can be optionally
increased to 900 mm.
The vertical dimensions are increased by 50 mm by this.
89013498-02; 2016-07; Changes reserved
