4 Product description
4.1 Mode of operation
The boiler and the tank fill and are warmed up to the operating temperature after the machine is switched on.
The display lights up in red during the warm-up phase. When the target temperatures are reached, the ma-
chine is ready for use. The display is lit in green.
The machine is fully automatic with programmes consisting of three steps: Wash, Drain and Rinse. Whilst a
washing programme is running, the display is lit in blue.
4.2 Overview
Upper rotating wash field
Lower rotating wash field
Bushings for cables and hoses
Suction tube for rinse aid
(blue cap and blue suction hose)
Suction tube for detergent
(black cap and transparent suction hose)
Hoses and cable for the suction tubes
Connection for local equipotential bonding
system
