Operating The Freedom SW 3000
Monitoring the Freedom SW 3000 Indicator
Lights
The ten indicator lights on the front panel show you the operating status of
the Freedom SW 3000. A description of the lights is provided in Table 3.
If none of the front panel lights are on, see “Troubleshooting Reference” on
page 47. Faults and Warnings
A fault affects the operation of the unit. A manual fault requires user
intervention by clearing the condition and then pressing the Reset button on
the inverter/charger’s front panel. See the System Control Panel Owner’s
Guide for information on clearing faults from the SCP.
A warning alerts you to a condition that could possibly affect operation of
the unit.
See “Faults and Warnings” on page 21 for more explanation on the
difference between faults and warnings.
Monitoring Status Messages on the SCP
Refer to “System Menu Map” on page 26 of the Configuration chapter.
Table 3 Front Panel Lights
Light
Illuminated Color Status Action or Status Item
AC Charge Green When the Freedom
SW 3000 is connected
to a qualified AC
source or a generator,
the External AC light
illuminates.
You can run your
appliances from an
AC source like the
utility grid or a
generator.
Inverter
Enable
Green When inverter mode is
enabled, the Inverter
Enable Light is
illuminated. If Utility
is unavailable and
operating conditions
are met, the Freedom
SW 3000 will produce
AC voltage to power
your loads.
You can run your
appliances from the
inverter.
Fault Red A fault has occurred
on the network.
Investigate and clear
the fault condition.
Table 3 Front Panel Lights
Light
Illuminated Color Status Action or Status Item
