975-0545-01-01 25
Configuration
This section contains information about all configurable settings and
procedures for the Freedom SW 3000.
It provides information on using the SCP to configure the Freedom SW
3000 settings. Please refer to the System Control Panel Owner’s Guide for
detailed information on how to use the SCP.
System Control Panel
The System Control Panel (SCP) provides configuration and monitoring
capability for all Xanbus-enabled devices on the network. All changes to
the configuration of the Freedom SW 3000 are made with the SCP. See
“Using the SCP” on page 13.
The front panel of the Freedom SW 3000 provides limited control,
including reset; charger enable and disable; and inverter enable and disable.
Enabling a function When a function is enabled, it is allowed to occur
but other conditions may have to be met before the function is activated or
turned on. For example, the charger function on the Freedom SW 3000 may
be enabled, but it will not charge unless qualified AC power is present.
Disabling a function When a function is disabled, it is not allowed to
occur and if it is occurring, it is terminated. Regardless of other conditions,
the function will not be activated. For example, even if AC power is
present, if the charger is disabled, the unit will not charge.
NOTE: These functions on the front panel can also be controlled from the
SCP.
