975-0545-01-01 61
Specifications
NOTE: Specifications are subject to change without prior notice.
All inverter specifications are at nominal conditions: ambient temperature
of 77 °F (25 °C), 3000 watt resistive load, 12 volts DC inverting on the
RS3000, 120 volts AC, unless otherwise specified.
All charging specifications are at nominal conditions: ambient temperature
of 77 °F (25 °C), 120 VAC, 60 Hz input, unless otherwise specified.
Physical Specifications
Base Unit Dimensions and Weight:
L × W × H 385×340×200 mm (15.2×13.4×7.9 in.)
Net Weight 30.9 kg (68.1 lbs)
Inverter Specifications
Output wave form Sine wave
Total harmonic voltage
distortion
<5%
Output power 3000 W continuous
Surge rating 6000 W for ten seconds
AC output voltage 120 VAC ± 5%
Input DC voltage rating 12 VDC nominal, 10 to 16 VDC
AC output frequency 60.0 ± 0.05 Hz
Power factor (lag or lead) 0 to 1.0
Peak efficiency >91%
Efficiency at 3000W >82%
No load power draw <3.5 A
DC low voltage shutdown 10 volts
DC over voltage shutdown 16 volts
Charger Specifications
Charging method Three-stage charge (Bulk, Absorption,
Float)
Two-stage charge (Bulk, Absorption)
The default charging method is three-
stage.
