38 Freedom SW 3000 Owner’s Guide
Configuration
Menu (Advanced)
The advanced menu lists settings that provide you with additional control
over Freedom SW 3000. However, you may not have to adjust these
settings as part of regular operation. For a listing of advanced menu items,
see “Menu (Advanced)” on page 38.
In addition to several items from the basic menu, the Freedom SW 3000
advanced menu contains the following sub-menus and commands:
• Configure Inv/Chg (Configure Inverter/Charger)
• View Device Info
When you select a sub-menu and press Enter, a list of menu items appears.
These settings are only visible if Advanced Menu is selected. To select the
Freedom SW 3000 Advanced Menu, see “Selecting the Freedom SW 3000
Advanced Menu” on page 28.
This section describes the menu items in detail. Each item is described as a
display or configurable setting, when to use the setting, and the outcome of
changing a setting.
Inverter
This feature is the same as described on the basic menu on page 33.
Charger
This feature is the same as described on the basic menu on page 33.
Power Share
This feature is the same as described on the basic menu on page 33.
Configure Inv/Chg (Configure Inverter/Charger)
Cfg Inv/Chg is a sub menu command. If you select this item, you’ll access a
list of sub-menu items. See “Configure Inv/Chg (Configure Inverter/
Charger)” on page 38.
Equalize
This feature is the same as described on the basic menu on page 34.
Clear Faults
This feature is the same as described on the basic menu on page 37.
View Device Info
For more information on this sub menu, Device Information, see “View
Device Info” on page 38.
Basic Menu
Purpose Selecting Basic Menu takes you back to the basic menu of the
Freedom SW 3000 only. Advanced menu items will no longer be visible on
the SCP.
When to use Use this setting when you want to return to the basic menu
of the Freedom SW 3000.
