64 Freedom SW 3000 Owner’s Guide
Specifications
Invert Power Derating vs. Ambient Temperature
The inverter/charger delivers up to 3000 watts of sine wave output power.
See figure below for temperature derating information.
If the unit is in elevated ambient temperature above 60 °C, you are required
to reduce power draw according to the figure to avoid over-temperature
shutdown.
Charger Mode
Charger output (bulk mode) is 150 amps DC to 40 °C ambient. In higher
ambients, the charger will automatically derate (reduce output current) to
maintain internal temperatures at a safe level. Output at 60 °C ambient is
approximately 75 amps.
Figure 28 Invert Power Derating versus Ambient Temperature
2200
3000
Maximum power available for at least one hour
Output Power (W)
Ambient Temperature (°C)
-20-100 102030405060
