Installation
16 975-0136-01-01
Putting the System in Safe Mode
In Safe mode, all Xanbus-enabled devices remain powered and continue
to communicate, and all device outputs are disabled.
To enter Safe mode:
1. On the Select Device menu, use the down arrow button to highlight
System, as shown in Figure 10.
The cursor on the right of the screen indicates where you are in the
menu.
2. Press Enter.
The System Settings menu appears.
3. On the System Settings menu, with Desired Mode highlighted, as
shown in Figure 11, press Enter.
4. Use the down arrow button to scroll through the other modes to select
Safe mode, as shown in Figure 12.
CAUTION: Unpredictable device behavior
Before removing or installing a device on an existing Xanbus System, you must
put the system into Safe mode from the System Control Panel.
Figure 10
Select Device Menu
Figure 11
System Settings Menu
