Printer System (Western Hemisphere)
Section Specification
Single Phase 2 wire, plus ground
15 Ampere
Line to Line Service 50/60Hz:
208-240 volts AC (+6%to -10%)
12 Ampere
Customer provided receptacle (or
equivalent)
NEMA Part No 6-15R
Frequency 50/60 Hz single phase
Power cord 250V/15A cable included with system
Power cord length 8.2 feet /2.5 M
Power cord must have dedicated use of
15 ampere outlet
This receptacle is also used for common
air conditioning units and is available at
most hardware stores.
6-15 R (NASG only. All others: Flying-leads)
Energy Star (eStar) Compliant
Receptacle Diagram (XNA only, All
others: Flying leads)
17
