Booklet Making Finisher (optional)
If installed, provides booklet making (with or without saddle stitching) and bi-fold, in addition to the
standard finisher and its features.
Booklet Making Finisher with post-process inserter
The booklet making finisher is fitted with the inserter and provides offset stacking, hole-punch,
stapling and bi-directional decurler. The stapler cuts staples to custom lengths automatically for
all staple operations other than booklet making. The booklet maker has a fixed length staple only.
Booklet finisher specifications
Specifications Condition
Paper size
11 in x 17 in /A3
8.5 in x 11 in / A4
8.5 in x 14 in
Inserter 175 sheets 16 lb Bond (60 gsm) to 90 lb Cover (220 gsm) (Coated
stock is not supported in this tray.)
Tray capacity
20 sets; stacks 2,000 sheets
Bi-fold skew
Less than 2.5 mm
Booklet skew
1.5 mm for A4; 2.0 mm for all others
Booklet thickness of
folded paper
on the open sides:
less than 22 mm with 5 sheets
less than 40 mm with 10 sheets
less than 65 mm with 15 sheets
Thickness of bi-fold
paper
less than 22 mm with A4
less than 30 mm with A3
Max stapling capacity
15 sheets
Staple position
double (2 staples)
+/- 1 mm staple skew from the crease; 120 mm +/- 1 mm from the top
staple to the top of the bottom staple; X1 mm +/- 2 mm from the edge
of the paper to the top of the top staple
Basis weight 16 lb Bond (60 gsm) to 24 lb Bond (90 gsm) or
1 cover sheet, up to 217 gsm, 14 sheets of 24 lb Bond (90 gsm)
28
