Xerox B1022 System Administrator Guide

LDAP Server
Lightweight Directory Access Protocol (LDAP) is a protocol used to process queries and updates to an
LDAP information directory, on an external server. LDAP can also be used for network authentication
and authorization.
The LDAP Server page displays the current LDAP servers configured for your printer. You can configure
a maximum of nine LDAP servers for your printer.
Note: Before you configure an LDAP server, ensure that Network Authentication is enabled. For
details, refer to Setting the Login Method.
AAddddiinngg oorr EEddiittiinngg aann LLDDAAPP SSeerrvveerr
1. In Xerox
®
CentreWare
®
Internet Services, click Properties→Connectivity→Protocols.
2. Click LDAP Directory.
3. To edit the default LDAP server settings, for LDAP (Default), click Edit.
4. To configure another LDAP server, for Additional LDAP Servers, click Add or Edit.
5. To configure server information, perform the following steps.
a. Type a Friendly Name. The Friendly Name appears as the default description for the server
when a user scans a job at the control panel.
b. Select the Name or IP Address type. Fields update based on the options that you select.
c. Type the LDAP IP address or host name and port number.
d. Type the appropriately formatted address or host name of your backup server, then change
the default port number as needed.
6. To configure LDAP Access, perform the following steps.
a. Enter the Search Directory Root.
Note:
• It is not necessary to include DC=Users in the Search Directory Root.
• For details on Base DN formatting, refer to the RFC 2849 - LDAP Data Interchange
Format (LDIF) Technical Specification on the IETF website.
b. For Login Credentials to Access LDAP Server, select an option.
• System: This setting instructs the printer to use specific credentials when the printer
accesses the server.
• Authenticated User: The printer uses the user name and password of the authenticated
user to access the server.
c. To look up the user DN, for Lookup User's DN, select Enable.
7. To configure LDAP Bind, perform the following steps.
30
Xerox
®
B1022 Multifunction Printer
System Administrator Guide
Network Connectivity

Xerox B1022 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Watermark printing	Yes
Time to first page (black, normal)	9.1 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Duplex print speed (black, normal quality, A4/US Letter)	11 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	7.8 s
Copy speed (black, normal quality, A4)	22 cpm
Faxing	No
Scan to	E-mail, FTP, PC, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed scanner
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIFF
Document formats supported	PDF
Total input capacity	350 sheets
Total output capacity	250 sheets
Maximum input capacity	600 sheets
Sound power level (standby)	30 dB
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1100 W
Power consumption (off)	2 W
Power consumption (ready)	80 W
Power consumption (sleep)	1 W
Power consumption (average operating)	550 W
Energy Star Typical Electricity Consumption (TEC)	1.2 kWh/week
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Product color	Black, White
Market positioning	Business
Package depth	750 mm
Package width	771 mm
Package height	600 mm
Package weight	32000 g
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	PCL 6, PostScript
Paper tray media types	Bond paper, Heavy paper, Letterhead, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm), Tabloid (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Included cartridge capacity (black)	2500 pages

Weight and Dimensions

Depth	555.3 mm
Width	560 mm
Height	417 mm
