Xerox B1022 System Administrator Guide

Setting Access Rights
You can control access to services and features by setting up authentication and authorization.
Personalization allows the printer to retrieve user information to customize features.
AAuutthheennttiiccaattiioonn
Authentication is the process of confirming user identities. If you enable authentication, the printer
compares the information that users provide to another source of information, such as an LDAP
directory. If the information is valid, the users are considered authenticated.
There are several ways to authenticate a user:
• Passcode: This option enables a passcode. To access the printer, at the control panel, users type a
passcode. The printer compares the passcode to the stored information.
•
Local Authentication: The option
enables local authentication. To prove their identity, users type
their user name and password at the control panel or in Xerox
®
CentreWare
®
Internet Services.
The printer compares the user credentials to the information stored in the user database. If you
have a limited number of users, or do not have access to an authentication server, use this
authentication method.
• Network Authentication: This option enables network authentication. To prove their identity,
users type their user name and password at the control panel or in Xerox
®
CentreWare
®
Internet
Services. The printer compares the user credentials to the information stored on an authentication
server.
Note: The printer can use one of the following authentication server types:
• Kerberos for UNIX, Linux, or Windows ADS
• SMB for Windows ADS or LDAP
SSeettttiinngg tthhee LLooggiinn MMeetthhoodd
1. In Xerox
®
CentreWare
®
Internet Services, click Properties→Login / Permissions.
2. Click Login Methods.
3. To set the authentication method, select an option:
• No Authentication: This option allows unrestricted access to the printer.
• Passcode: This option creates the passcode for users to enter at the control panel. For Create
Passcode, type a password.
• Local Authentication: This option stores user login information on the printer in the Device
User Database. To configure the database, for Device User Database, click the Pencil icon.
• Network Authentication: This option stores user login information on an authentication
server in the network. To configure the server connection, for Authentication Server, click the
Pencil icon.
Note: If you select Local Authentication or Network Authentication, you can set the printer
to retrieve user profile information from LDAP. To retrieve information from LDAP, for
Personalize Local UI, select Retrieve Profile Information for Authenticated User from
LDAP. To configure the server connection, for LDAP Server, click the Pencil icon.
44
Xerox
®
B1022 Multifunction Printer
System Administrator Guide
Security

Xerox B1022 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Watermark printing	Yes
Time to first page (black, normal)	9.1 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Duplex print speed (black, normal quality, A4/US Letter)	11 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	7.8 s
Copy speed (black, normal quality, A4)	22 cpm
Faxing	No
Scan to	E-mail, FTP, PC, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed scanner
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIFF
Document formats supported	PDF
Total input capacity	350 sheets
Total output capacity	250 sheets
Maximum input capacity	600 sheets
Sound power level (standby)	30 dB
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1100 W
Power consumption (off)	2 W
Power consumption (ready)	80 W
Power consumption (sleep)	1 W
Power consumption (average operating)	550 W
Energy Star Typical Electricity Consumption (TEC)	1.2 kWh/week
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Product color	Black, White
Market positioning	Business
Package depth	750 mm
Package width	771 mm
Package height	600 mm
Package weight	32000 g
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	PCL 6, PostScript
Paper tray media types	Bond paper, Heavy paper, Letterhead, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm), Tabloid (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Included cartridge capacity (black)	2500 pages

Weight and Dimensions

Depth	555.3 mm
Width	560 mm
Height	417 mm
