Wireless Network Connection
A wireless local area network (WLAN) provides the means to connect two or more devices in a local
area network (LAN) without a physical connection. The printer can connect to a wireless LAN that
includes a wireless router or wireless access point. Before connecting the printer to a wireless network,
ensure that the wireless router is configured with a service set identifier (SSID), a passphrase, and
security protocols.
Note: Before configuring wireless network settings, install the Xerox Wireless Network Adapter
Kit. For information, refer to the Hardware Install and Setup instructions that are included with
the kit.
CCoonnnneeccttiinngg ttoo aa WWiirreelleessss NNeettwwoorrkk MMaannuuaallllyy
When connecting to a wireless network that does not include a WPS-compliant router, set up and
configure the printer manually. Before starting, you must get the setup and configuration
information, such as name and passphrase, from the router. After you collect the network
information, you can set up the printer from the control panel or from Xerox
®
CentreWare
®
Internet Services. For the easiest manual connection, use Xerox
®
CentreWare
®
Internet Services.
Before you begin:
• The wireless router must be connected and properly configured for the network before you install
the printer. For details, see your router documentation.
• Use the instructions provided with your wireless router or access point to record the following
information:
– Name (SSID)
– Security Options (Encryption Type)
– Passphrase
Note: The network name and passphrase are case sensitive.
CCoonnffiigguurriinngg tthhee PPrriinntteerr ffoorr WWiirreelleessss LLAANN WWPPAA--EEnntteerrpprriissee
1. In Xerox
®
CentreWare
®
Internet Services, click Properties→Connectivity→Protocols.
2. Click Wireless Setup.
3. Click Edit Settings.
4. For Network Name SSID, select an option:
• Select the Search Available option, then, from the list, select a network.
Note: To refresh the list of available networks, click Refresh.
• Select the Enter SSID option, then, in the field, type the SSID.
5. For Security Type, select WPA/WPA2-Enterprise.
6. For Encryption Type, select an option.
7. For 802.1x Authentication, select an option.
• If you select EAP-TTLS, select an Inner Authentication Protocol, then type an Identity Name,
User Name, and User Password.
• If you select PEAP, type a User Name and User Password.
Xerox
®
B1022 Multifunction Printer
System Administrator Guide
39
Network Connectivity
