Maintenance
Phaser 7500 Color Printer
User Guide
101
2. Rotate the lever on the front left side to unlock it.
3. Open the imaging unit cover.
4. Pull the cleaning rod from the lower right corner of the imaging unit slot.
5. Pull out the cleaning rod until it stops, then move it all the way in and out two or three times to
clean the LEDs. Repeat this for all four imaging units.
Note: Make sure to pull the cleaning rods out as far as they will go. Push them in as far as they will
go. Do not use excessive force.
7500-081
7500-074
7500-077
4X
To Next Page
