Xerox VersaLink B610 User Manual

• Adjusting the paper guides improperly
Most jams can be prevented by following a simple set of rules:
• Use only supported paper. For more information, refer to Supported Paper.
• Follow proper paper handling and loading techniques.
• Always use clean, undamaged paper.
• Avoid paper that is curled, torn, moist, creased, or folded.
• To separate the sheets before loading into the tray, fan the paper.
• Do not load paper above the maximum fill line.
• After loading paper in the trays, adjust the paper guides in all trays. A guide that is not properly adjusted can
cause poor print quality, misfeeds, skewed prints, and printer damage.
• After loading paper in the trays, at the control panel, select the correct paper type and size.
• Before printing, select the correct paper type and size in the print driver.
• Store paper in a dry location.
The following can cause paper jams:
• Polyester-coated paper that is designed especially for inkjet printers
• Paper that is folded, wrinkled, or excessively curled
• Loading more than one type, size, or weight of paper in a tray at the same time
• Loading paper above the maximum fill line in the paper tray
• Allowing the output tray to become overfilled
For a detailed list of supported paper, refer to Supported Paper.
CLEARING PAPER JAMS
Clearing Paper Jams from the Bypass Tray
To resolve the error displayed on the control panel, you must clear all paper from the paper path.
1. Remove any paper from the Bypass Tray.
156 Xerox
®
VersaLink
®
B600/B610 Printer User Guide
Troubleshooting

Xerox VersaLink B610 Specifications

General

Package depth	640 mm
Package width	580 mm
Package height	610 mm
Package weight	28000 g
Country of origin	Vietnam
Maximum resolution	1200 x 1200 DPI
Optional connectivity	Wireless LAN
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Sustainability certificates	ENERGY STAR
Operating relative humidity (H-H)	10 - 85 %
Printing colors	Black
Maximum duty cycle	300000 pages per month
Number of print cartridges	1
Page description languages	HP-GL, PCL 5e, PCL 6, PostScript 3, TIFF, XPS
Average cartridge yield (black)	30000 pages
USB port	Yes
Color	No
Print technology	Laser
Warm-up time (from sleep mode)	35 s
Time to first page (black, normal)	3.7 s
Print speed (black, normal quality, A4/US Letter)	63 ppm
Duplex print speed (black, normal quality, A4/US Letter)	56 ppm
Paper input type	Paper tray
Total input capacity	700 sheets
Total output capacity	500 sheets
Custom media width	76.2 - 190 mm
Custom media length	216 - 356 mm
Duplex media weight	60 - 176 g/m²
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 220 g/m²
Maximum ISO A-series paper size	A4
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP, HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP, FTP
Storage media	HDD
Internal memory	2048 MB
Processor cores	2
Processor family	ARM Cortex
Internal storage capacity	320 GB
Sound power level (standby)	27.1 dB
Sound pressure level (printing)	56.8 dB
Current rating	8 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	72 W
Power consumption (printing)	900 W
Control type	Touch
Product color	Blue, White
Market positioning	Business
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Cables included	AC
Compatibility	VersaLink B600/B610

Weight and Dimensions

Depth	465.5 mm
Width	427.4 mm
