Xerox VersaLink B610 User Manual

3. To view a list of specific job types, touch an option.
• To view Saved Jobs, touch SSaavveedd JJoobbss. To print the job, touch the job, enter the quantity, then touch OOKK. To
delete the job, touch the TTrraasshh icon, then touch DDeelleettee.
• To view Personal jobs, touch PPeerrssoonnaall && SSeeccuurree JJoobbss. To print the jobs, touch the folder, then touch PPrriinntt
AAllll, or DDeelleettee AAllll.
• For Secure Jobs, touch PPeerrssoonnaall && SSeeccuurree JJoobbss. Touch the folder, enter the passcode number, then touch
OOKK. To print a Secure Job, touch the job. To print or delete all the jobs in the folder, touch PPrriinntt AAllll, or
DDeelleettee AAllll.
4. To view details about a job, touch the job.
5. To return to the Home screen, press the HHoommee button.
Printing a Job Held for Resources
1. At the printer control panel, press the HHoommee button.
2. Touch JJoobbss.
3. From the jobs list, touch the held job name. The resources required for the job appear on the control panel.
4. Do one of the following:
• To print the job, replenish the resources required. The job resumes automatically when the required
resources are available. If the job does not print automatically, touch RReessuummee. Select from the following
options:
• DDeelleettee JJoobb: To delete the print job that is on hold, touch DDeelleettee.
• RReellooaadd MMeeddiiaa: To load recommended media in the feeder, touch RReellooaadd MMeeddiiaa.
• CChhaannggee MMeeddiiaa: If the recommended media is unavailable, to print on alternate media, touch CChhaannggee
MMeeddiiaa.
Note: If the new media size is smaller than the size specified in original print job, valid data outside the
printable area of the new media will be cut off.
• To delete the print job, touch DDeelleettee. At the prompt, touch DDeelleettee.
5. To return to the Home screen, press the HHoommee button.
MANAGING SPECIAL JOB TYPES
Special job types allow you to send a print job from your computer, then print it from the printer control panel.
Select special job types in the print driver, Printing Options tab, under Job Type.
Saved Jobs
Saved Jobs are documents sent to the printer and, unless deleted, are stored there for future use. Any user can print
or delete a Saved Job.
To print a Saved Job, refer to Printing a Saved Job.
76
Xerox
®
VersaLink
®
B600/B610 Printer User Guide
Xerox
®
Apps

Xerox VersaLink B610 Specifications

General

Package depth	640 mm
Package width	580 mm
Package height	610 mm
Package weight	28000 g
Country of origin	Vietnam
Maximum resolution	1200 x 1200 DPI
Optional connectivity	Wireless LAN
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Sustainability certificates	ENERGY STAR
Operating relative humidity (H-H)	10 - 85 %
Printing colors	Black
Maximum duty cycle	300000 pages per month
Number of print cartridges	1
Page description languages	HP-GL, PCL 5e, PCL 6, PostScript 3, TIFF, XPS
Average cartridge yield (black)	30000 pages
USB port	Yes
Color	No
Print technology	Laser
Warm-up time (from sleep mode)	35 s
Time to first page (black, normal)	3.7 s
Print speed (black, normal quality, A4/US Letter)	63 ppm
Duplex print speed (black, normal quality, A4/US Letter)	56 ppm
Paper input type	Paper tray
Total input capacity	700 sheets
Total output capacity	500 sheets
Custom media width	76.2 - 190 mm
Custom media length	216 - 356 mm
Duplex media weight	60 - 176 g/m²
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 220 g/m²
Maximum ISO A-series paper size	A4
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP, HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP, FTP
Storage media	HDD
Internal memory	2048 MB
Processor cores	2
Processor family	ARM Cortex
Internal storage capacity	320 GB
Sound power level (standby)	27.1 dB
Sound pressure level (printing)	56.8 dB
Current rating	8 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	72 W
Power consumption (printing)	900 W
Control type	Touch
Product color	Blue, White
Market positioning	Business
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Cables included	AC
Compatibility	VersaLink B600/B610

Weight and Dimensions

Depth	465.5 mm
Width	427.4 mm
