37
Drum Cartridge Replacement
The useful life of the drum cartridge is 12,000 copies. When the drum
cartridge indicator lights a replacement cartridge will be needed soon.
Copies can continue to be made, but you should keep a replacement
cartridge. After a further 1,000 copies, the Ready indicator will go out, the
drum cartridge indicator will flash, and the copier will stop operating until
the drum cartridge is replaced.
1. Press the release lever to open the
copier.
2. Press down on the toner cartridge
lever (1) and pull out the cartridge (2).
Note: The toner cartridge must be removed
before removing the drum cartridge.
3. Pull out the drum cartridge.
4. Remove the cover from the new drum
cartridge.
5. Slide the new drum cartridge in place,
making sure not to touch the surface of
the drum.
6. Replace the toner cartridge.
7. Gently push down the upper half of the
copier to close it.
