System Voltages
Select
System Voltages
from the Advanced Chipset Features menu and press
Enter
to display the System Voltages menu.
Figure 12. System Voltages Menu
CPU Core
Use the
Page Up
and
Page Down
keys to scroll through the voltages or select
[Auto]
to automatically set the voltage level for the CPU Core.
CPU FSB
Use the
Page Up
and
Page Down
keys to scroll through the voltages or select
[Auto]
to automatically set the voltage level for the CPU FSB.
Memory
This function defines the voltage level for the DRAM. Use the
Page Up
and
Page Down
keys to select a voltage or select
[Auto]
to automatically set the
voltage.
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F7:Defaults
Parameters Settings Current Value
CPU Core [Auto] 1.28
CPU FSB [Auto] 1.2V
Memory [Auto] 1.85V
nForce SPP [Auto] 1.30V
nForce MCP [Auto] 1.50V
HT nForce SPP <-> MCP [Auto] 1.20V
nForce MCP Auxiliary [Auto] 1.50V
GTLVREF Lane 0 [Auto] +00mv
GTLVREF Lane 1 [Auto] +00mv
GTLVREF Lane 2 [Auto] +00mv
GTLVREF Lane 3 [Auto] +00mv
Item Help
Main Level
Voltage level for CPU
Core (CPU VID)
Phoenix – AwardBIOS CMOS Setup Utility
System Voltages
To Next Page
