Board Component Location
The following table idenes the components, references the respecve schemac (0381874)
page numbers, and links to a detailed funconal descripon of the components and board
features in Chapter 3: Board Component Descripons.
Table 3: Board Component Locations
Callout Feature [#] = Bottom Notes
Schematic
Page
Number
1 Spartan-7 XC7S100 FPGA (U1) XC7S100-2FGGA676C
2 1Gb QSPI Flash 4-bit [U3] Micron MT25QL01GBBB8ESF-0SIT 4
3 Direct QSPI Flash Program Header (J37) 2X5 1.27 mm
pitch male header
Samtec FTSH-105-01-F-DV 3
4 DDR3L Component Memory (U12) Micron MT41K256M16TW 7
5 IIC EEPROM [U27] ST Microelectronics M24C32-WDW6 8
6 I2C Programmable Clock, LVDS [U45] Silicon Labs SI570BAB000875DG
(default 33.3333 MHz)
8
7 FMC LPC Connector J21 Samtec ASP-134603-01 15-16
8 10/100/1000 Mb/s Tri-speed Ethernet PHY (RGMII)
with RJ45, SGMII mode only (U14), (J9)
TI DP83867IRPAP with Wurth
7499111221A RJ45 (with magnetics)
9
9 10/100/1000 Mb/s Tri-speed Ethernet PHY (RGMII)
with RJ45, SGMII mode only (U16), (J11)
TI DP83867IRPAP with Wurth
7499111221A RJ45 (with magnetics)
10
10 MIPI-CSI Camera Serial Interface (J8) TE Connectivity 1-1734248-5 8
11 MIPI-DSI Display Serial Interface (J20) Hirose FH34SJ-34S-0.5SH 11
12 HDMI Video Output (U18), (J13) Analog Devices ADV7511KSTZ, Molex
47151-1001
12,13
13 USB UART Interface, USB bridge (U6) with micro-AB
USB connector (J5), and 2x7 2 mm keyed program
cable connector (J3)
FTDI FT4232HQ_QFN64, Hirose ZX62D-
AB-5P8(30), Molex 87832-1420
3, 5
14 System Controller MSP430 (U25) TI MSP430F5342IRGZ 19
15 System Controller MSP430 4-pole GPIO DIP switch
(SW2)
Wurth 416131160804 19
16 System Controller MSP430 reset pushbutton (SW3,
active-Low)
Panasonic EVQ-11L07K 19
17 I2C Bus Switch (U23)
I2C_MSP430 Bus Port Expander (U24)
TI TCA9548A
TI TCA6416A
19
18 PMOD Interface 6x 2x6 Rt-Angle receptacles (J14-J19) Sullins PPPC062LJBN-RC 17
19 User 8x LEDs, Green, active-High (D6-D13) Lumex SML-LX0603GW-TR 21
20 User 6x pushbutton, active-High (SW4-SW9) E-Switch TL3301EF100QG 21
21 User 2x 8-pole DIP switch, 1.27 mm pitch, active-High
(SW10, SW12)
Wurth 416131160808 21
22 FPGA Program pushbutton, (SW1), active-Low Omron B3U-1000P 3
23 Power Input Connector, 2x6 (J30) Molex-39-30-1060 23
24 Power On/Off Slide Switch (SW11) C&K 1101M2S3AQE2 23
25 SP701 Board Power System, MPS (top and bottom) Monolithic Power Systems (MPS) 24-26
Chapter 2: Board Setup and Configuration
UG1319 (v1.0) July 12, 2019 www.xilinx.com
SP701 Board User Guide 11
