Xilinx Spartan-6 User Manual

14 www.xilinx.com Spartan-6 FPGA GTP Transceiver SIS Kit (HyperLynx)
UG396 (v1.0) June 10, 2010
Chapter 1: Spartan-6 FPGA GTP Transceiver Signal Integrity Simulation Kit
Adjusting Simulation Settings
1. Click Run Interactive Simulation (Oscilloscope) under the Simulate tab.
2. Select the Eldo/ADMS radio button under the Start Simulation button, as shown in
Figure 1-6.
X-Ref Target - Figure 1-6
Figure 1-6: Assign Probes, Select Eldo as Simulation Engine, and
Specify Stimulus Type
Select and Configure Stimulus
Select Eldo Simulation Engine
UG396_c1_06_051310
Ignore
Select Nodes to be Plotted
Spartan-6 FPGA Equalizer Outputs
