Xilinx Spartan-6 User Manual

Spartan-6 FPGA GTP Transceiver SIS Kit (HyperLynx) www.xilinx.com 7
UG396 (v1.0) June 10, 2010
Chapter 1
Spartan-6 FPGA GTP Transceiver
Signal Integrity Simulation Kit
Introduction
The Spartan®-6 FPGA GTP Transceiver Signal Integrity Simulation (SIS) Kit for Mentor
Graphics HyperLynx provides a simulation environment for evaluating channel designs
for Spartan-6 FPGA GTP transceivers. This document explains how to install the SIS kit
and associated files, gives an overview of the SIS kit file hierarchy, and describes the steps
for getting started with simulations. The appendices describe how the HyperLynx and
Eldo simulation results are correlated with the HSPICE simulations. Results are
documented with waveform plots.
Additional information on the models, ports, and options is available in
UG3
86, Spartan-6 FPGA GTP Transceivers User Guide.
Release Notes for the GTP Transceiver SIS Kit
Table 1-1 shows the UG396 document version and the associated Spartan-6 FPGA GTP
Transceiver SIS Kit version.
Installation and Requirements
The software requirements and the installation instructions for the Spartan-6 FPGA GTP
Transceiver SIS Kit are provided in this section.
SIS Kit Version 1.0
The requirements for the GTP Transceiver SIS Kit are:
• HyperLynx 8.0, build number 433 or later
• Microsoft Windows XP Professional, version 2002, Service Pack 3
To install the GTP Transceiver SIS Kit, follow these steps:
1. Unzip the ZIP file into any directory, provided that the path name does not contain any
spaces.
Table 1-1: Document and SIS Kit Version Correlation
UG396 Version SIS Kit Version
1.0 1.0
