GTP Transceiver Model Correlation
GTP Transceiver Model Correlation
Figure B-4 through Figure B-16 contain the waveform overlays of the correlation
simulations for the GTP transceiver models.
Note:
The blue waveforms cannot be seen because the red waveforms are covering them.
X-Ref Target - Figure B-4
Figure B-4: TXDIFFCTRL = 0000, TXPREEMP = 000, RXEQMIX = 00 (Typical - GTP Transceiver)
UG396_aB_04_051410
02
Eldo
FOM=99.8776%
HSPICE
145
Time (ns)
Volts
(Vppd)
63
-0.8
-0.6
-0.4
-0.2
0
0.2
0.4
0.6
0.8
02
Eldo
FOM=99.8921%
HSPICE
145
Time (ns)
Volts
(Vppd)
63
-0.8
-0.6
-0.4
-0.2
0.2
0
0.4
0.8
0.6
Typical, TXDIFFCTRL=0000, TXPREEMPHASIS=000, RXEQMIX=00 − MGTTX
Typical, TXDIFFCTRL=0000, TXPREEMPHASIS=000, RXEQMIX=00 − MGTRXOUT
