Rev.: 20191108
Platform: DBALL2
Firmware: BMW03
© 2019 Directed. All rights reserved.
To enter feature programming routine
Turn the ignition ON, then OFF.
Within 5 seconds, press and HOLD the programming button until the LED turns ON orange (after 3 seconds). Release the
Programming button.
The LED will flash green once slowly to indicate the feature number is 1. After a short delay, the LED flashes red rapidly to indicate
the current option of feature 1 (i.e. 1x green followed by 1x red indicates feature 1 is set to option 1). The flashing sequence will
repeat until a new command is entered.
Changing feature options
Press the lock/arm or unlock/disarm button on aftermarket transmitter to change the option of the selected feature.
The LED flashes red rapidly the number of times equal to the current option number. After a short delay, the LED flashes green
slowly the number of times to indicate the current feature. The flashing sequence will repeat until a new command is entered.
Accessing another feature
Press and release the programming button a number of times to advance from the current feature to the next desired feature.
The LED flashes green slowly the number of times equal to the feature number. After a short delay, the LED flashes red rapidly to
indicate the current option of the current feature. The flashing sequence will repeat until a new command is entered.
When the maximum number of features or options is reached, the LED will start flashing again from the first feature or
option.
Once a feature is programmed
Other features can be programmed.
The feature programming can be exited.
Exiting feature programming
No activity for 30 seconds; after 30 seconds, the LED will turn ON orange for 2 seconds to confirm the end of the programming
sequence.
OR
Press and HOLD the programming button for 3 seconds. After 3 seconds, the LED will turn ON orange for 2 seconds to confirm
the end of the programming sequence.
Feature Programming
Programming
Button
Feature & Option List
It is recommended to configure all the features and options listed below using the configuration tool found on the module
flashing page on www.xpresskit.com. The web offers more options; however, a manual configuration of the features is
possible using the information on this page.
Feat. Operation Flashes/Options Description
1. No RF Output*
Module is connected to a remote starter using a standard installation.
3. RFTD Output
Module is connected to an XL202 using an RSR or RXT installation (when available).
2. SmartStart Module is connected to SmartStart using an RSR or RXT installation (when available).
1. Disabled*
2. Enabled
1. Key Slot or Smart Key*
2. Mechanical Key
1. Disabled*
Remote Start will shut down when door opens.
2. Enabled Enabled 45 seconds after unlock.
1. OFF*
2. Windows Roll Up
3. Front Windows Roll Down
4. Rear Windows Roll Down
1. OFF*
2. Windows Roll Up
3. Front Windows Roll Down
4. Rear Windows Roll Down
RFTD Output Type1
2 Comfort Closure
AUX 15
6 AUX 2
3 Key Interface Type
4 Takeover
* Default Option
Page 14
