Xtralis VESDA-E VEU-A00 User Manual

VESDA-EVEU-A00 Product Guide
www.xtralis.com 97
A Commissioning Forms
This is the main commissioning form for each customer site.
TableA-1: VESDA-E commissioning form
Customer Name
Site Address
Installer (Name &Contact)
Commissioner (Name &Contact)
Commissioning Checks Done (Y/N) Notes
Aspirator speed setting and pipes in use configured as per
ASPIRE.
Detector alarm thresholds configured.
Detector Normalised.
GPI connected and tested (if used).
Reset detector – Check that detector is running with no
faults.
The alarm and fault relay outputs are wired to the fire
panel.
Test the detector’s Relay outputs connection to the fire
panel using the Xtralis VSC Relay Test command. (Turn
each relay on/off individually.) See below.
Relay 1 Tested (Default assignment = Disable)
Relay 2 Tested (Default assignment = Minor Fault)
Relay 3 Tested (Default assignment = Urgent Fault)
Relay 4 Tested (Default assignment = Alert)
Relay 5 Tested (Default assignment = Action)
Relay 6 Tested (Default assignment = Fire 1)
Relay 7 Tested (Default assignment = Fire 2)
Fire 1 relay connection from Detector to fire panel tested
(using the Xtralis VSC Alarm Test command).
Urgent Fault relay connection to fire panel tested (using
the Xtralis VSC Urgent Fault Test command).
Minor Fault relay connection to fire panel tested (using the
Xtralis VSC Minor Fault Test command).
Smoke Test done. Transport time tested.
