Xtralis vesda LaserFOCUS VLF-500 User Manual

LaserFOCUS VLF-500 Product Guide VESDA
®
2
Dimensions
Figure 1 - Dimensions of the detector
Figure 2 - Dimensions of detector with mounting bracket
Legend
mm inches
A 256 10.08
B 182.8 7.20
C 134.0 5.28
D 204.0 8.03
E 36.0 1.42
F 25.5 1.00
G 27.0 1.06
H 92.1 3.63
I 182.8 7.20
J 180.0 7.09
Legend
mm inches
A 236.3 9.30
B 120.0 4.72
C4.50.18
D 230.0 9.06
E 100.0 3.94
F 50.0 1.97
G 40.0 1.57

Xtralis vesda LaserFOCUS VLF-500 Specifications

General

Brand	Xtralis
Model	vesda LaserFOCUS VLF-500
Category	Smoke Alarm
Language	English
