LaserFOCUS VLF-500 Product Guide VESDA
®
28
Controls and indicators
Control buttons are accessed by opening the field service access door. This door is opened by
pressing in the security tab, on the right side of the detector, with a flat screw driver and then
lifting the door by the finger clips on each side of the door (see Figure 3, “Field Service Access
Door security tab and clip,” on page 4).
Figure 25 - Field Service Access Door security tab and clip
Legend
A Security tab
B Finger clip
C Field service access door
B
A
C
