Basic Operations
Turning the power on
1 Press the “|” side of the POWER switch
The power will be switched on, and the power supply monitor (LED indicator) will
illuminate.
Tips • When the power is supplied from the AC IN jack, the indicator illuminates in green.
• When the power is supplied through the BACKUP terminals (12 V DC), the indicator illuminates
in red.
The operation mode screen will appear on the display.
Switching the power off
1 Press the “O” side of the POWER switch
The power supply monitor and the display will turn off, and the power will be switched off.
Setting the ID (call sign)
When switching the power on for the first time after purchasing, or after resetting the radio, you must enter the call sign.
1 Touch [F] in the setup mode screen
The setup menu will appear.
2 Touch [ID SET]
The character input screen will appear.
5'672
᳁
Ჿ
Ჸ
Ჸ
7
2
0
-+
.
0
-+
.
Ჸ
Ჽ
Ჸ
Ჸ
&1
90
(
/8 53.
6Z294
*+
$#%-
$#%-
+&5'6
+&# 00170%'
/1&'4'/16'
616
&53%1&'
OKP
5+)0#.+0)
53.
41((
61((
3 Touch a character key
The touched character will be displayed at the top of the screen.
Tips • Each time [ ] is touched the cursor will move to the left and erase one character.
• The input screen changes between numbers input and alphabet input each time [ABC] is
touched.
• The cursor in the input field moves left or right when [←] or [→] are touched.
• Alphabets, numbers, and a hyphen up to 10 characters can be entered.
3 9 ' 46; 7 +12
# 5 &()*, - .
<:%8$0/
#$% 5RCEG
@
ᲹᲺ
%CRU
$#%-
+&5'6
4 Touch [ENT]
The ID setting is saved and the display will return to the setup menu.
Tip When switching the power ON for the first time after purchasing, or after resetting the radio, a
screen will be displayed requesting the repeater ID be entered.
3 9 ' 46; 7 +12
# 5 &()*, - .
<:%8$0/
#$% 5RCEG
'06
@
ᲹᲺ
%CRU
+&5'6
2
%
ᲹᲹ Ჺ
;
*,
