FTA-450L OperATing MAnuAL
10

MIC/SP
Jack
You may connect the supplied
SCU-15
Headset
Adapter Cable, the optional
SSM-10A
Speaker/
Microphone or the optional
SEP-11A
Earphone to
this jack. To use this jack, you must rst remove the
cover from the transceiver body.
Do not allow the
FTA-450L
to get wet
while the MIC/SP cover has been removed.

DATA
Jack
You may connect the optional USB cable to this
jack. To use this jack, you must rst lift the rubber
cover away from the transceiver body.
Do not allow the
FTA-450L
to get wet
while the rubber cover is removed.

EXT DC
Jack
When an external 9.5- to 10.5-Volt DC power
source is available, you may connect the
SDD-12
Cigarette Lighter DC/DC Converter here. To use
this jack, you must rst lift the rubber cover away
from the transceiver body.
1) Do not allow the
FTA-450L
to get wet
while the rubber cover is removed.
2) Do not connect any accessory unap-
proved by YAESU to supply DC power.
Controls & ConneCtors
(
rIght sIde
)



DATA
MIC/SP
EXT
DC
PTT
SQL
