8-38
EBU01112
Wheel removal
1. Loosen the wheel nuts.
2. Elevate the ATV and place a suitable
stand under the frame.
3. Remove the nuts from the wheel.
4. Remove the wheel.
EBU11211
Wheel installation
1. Install the wheel and the nuts.
NOTE:
_
●
The arrow mark on the tire must point
toward the rotating direction of the wheel.
●
Tapered nuts are used for both the front
and rear wheels. Install the nut with its ta-
pered side towards the wheel.
_
1. Arrow mark
EE.book Page 38 Wednesday, June 23, 2004 1:13 PM
