4-18
6X4 MULTI-FUNCTION TILLER HANDLE
MULTI-FUNCTION TILLER HANDLE KIT (FOR EU & ANZ)
Both tiller handle kit and fitting kit are required for installation.
TILLER HANDLE KIT CONTENTS
F30 – F115
KIT P/N:6X4-42103-64
HANDLE FITTING KIT CONTENTS
F30 – F40
KIT P/N: 6X4-42102-81
Part name Part No. Q’ty Remarks
Tiller handle ASSY 6BC-42101-23 1 w/o Troll RPM SW. Requires fitting kit.
Setup manual 6X4-2819K-K7 1 English, French, Spanish
Part name Part No. Q’ty Remarks
Cable clamp 1 63D-48538-00 2
Shift cable 67C-48321-11 1
Throttle cable 69W-26301-00 1
Cap 6X4-42728-00 1 For PTT SW
Troll rpm SW ASSY 6X4-81860-00 1
Wire harness 6X4-82586-10 1
Wire lead 6X4-83653-20 1 L=700 mm (27.6 in.)
Bolt 90109-06M88 2
locknut 90185-10027 2 M10
Clamp 90464-09M42 1
Clamp 90465-13M36 1
Clip 90468-10005 2
Washer 92990-06100 2
Friction piece 65W-42528-00 2
Friction plate 1 67C-42525-00 1
Friction plate 3 67C-42527-03 1
Steering lock knob 67C-42561-00 1
Steering lock shaft 67C-42562-00 1
Tilt lever cover 68943-63300 1
locknut 90185-10M14 1
Washer 90201-106M5 1
Plate washer 90202-10M56 1
Washer 90209-10M26 1
Collar 90387-05053 1
Collar 90387-05054 1
Nut 95380-05600 1
Bolt 97595-05520 1
