OPTIONAL EQUIPMENT
NMEA2000 GATEWAY
Used to connect between NMEA2000 compatible equipment and network hub.
ANALOG GAUGE INTERFACE (IF)
Used to connect between analog gauge and network hub.
Part No. Remarks
6Y9-8A2D0-20 Compatible with 6Y8 and 6Y9 protocols
Part No. Remarks
6Y9-8A2D0-30 Compatible with 6Y8 and 6Y9 protocols, Required for each engine.
5.5
(0.22)
20.5
(0.81)
116 (4.57)
130 (5.12)
To NMEA2000
equipment
To network hub
via wire-lead
6Y9-83553-50
12 (0.47)
1.8 (0.07)
4.8 (0.19)
56 (2.20)
7.8 (0.31)
500 (19.7)
20
YELLOW
mm (in.)
1.8 (0.07)
4.6 (0.18)
7.8 (0.31)
To wire-harness
6Y5-83553-00
To analog
tachometer via
trim/oil lead
6Y5-83653-*0
To hub
via wire-lead
6Y9-83553-50
12 (0.47)
16 (0.63)
116 (4.57)
130 (5.12)
400 (15.8)
Engine selection for analog tachometer:
56 (2.20)
5.5
(0.22)
20.5
(0.81)
BOrBLBOrBL BOrBLBOrBL
——
——
—
CENTER engine
CENTER PORT engine CENTER STBD engine STBD engine
PORT engine
PORT engine
PORT engine
PORT engine
Quad engine
Single engine
Twin engine
Triple engine
—
STBD engine
STBD engine
30
mm (in.)
