Yamaha F200CET User Manual

9-11
CONVENTIONAL RIGGING KIT CONTENTS
TWIN-MOTOR KIT
Above L150 (except L250G), Above FL/LF115
P/N: 6YR-W0035-G7
Part name Part No. Q’ty Remarks
Wire-lead 6Y5-83553-20 1 2.5 m (8 ft) w/10 amp fuse
Tachometer ASSY 6Y5-8350T-91 1 Includes instruction tag
EXT wire-lead 6Y5-83653-40 1 9 m (31 ft)
Twin-binnacle RCL box 704-48207-P1 1 Premium
Main wire-harness, 10-pin 6K1-8258A-40 1 8 m (26 ft)
Main wire-harness, 10-pin 61B-8258A-01 1 9.5 m (32 ft)
Clamp 90465-13M18 10
Twin-switch panel 6K1-82570-12 1 With multi-engine system
Screw 90149-05M05 4 25 mm (0.1 in)
Nut 95380-05600 4
Plane washer 92990-05600 4
Spring washer 92990-05100 4
Fuel mgt gauge 6Y5-8350F-01 1 With 3-prong connector
Wire-lead 6Y5-83553-F1 1 8 m (26 ft)
Fuel flow sensor 6Y5-85752-02 2
Screw 90158-06003 4 68 mm (2.7 in)
Instruction 61B-28107-A4 1

Yamaha F200CET Specifications

General

Brand	Yamaha
Model	F200CET
Category	Outboard Motor
Language	English
