Yamaha F40BED - Procedure for Tilting up

Operation
34
2. Disconnect the fuel line from the out-
board motor.
3. Place the tilt lock lever in the release po-
sition.
4. Hold the rear of the top cowling with one
hand, tilt the engine up, and turn the tilt
support lever toward you or tilt support
knob into the clamp bracket, and then
place the tilt lock lever back into the lock
position to support the outboard motor.
EMU28005
Procedure for tilting up
Power trim and tilt models / power tilt models
1. Place the remote control lever / the gear
shift lever in neutral.
N
ZMU03087
N
FR
ZMU04062
ZMU04063
ZMU04064
ZMU04065
N
ZMU03196
