Yamaha F70 User Manual

Operation
74
3. Push the power trim and tilt switch “ ”
(down) to lower the outboard motor to
the desired position.
EMU28062
Shallow water
EMU32851
Power trim and tilt models
The outboard motor can be tilted up partially
to allow operation in shallow water.
NOTICE
ECM00260
Do not tilt the outboard motor up so that
the cooling water inlet on the lower unit is
above the surface of the water when set-
ting up for and cruising in shallow water.
Otherwise severe damage from overheat-
ing can result.
EMU32913
Procedure for power trim and tilt models
1. Place the remote control lever / gear
shift lever in neutral.
ZMU03644
DN
ZMU01936
UP
DN
DN
ZMU07921
6C1-9-3B-1E0.book 74 ページ ２０１２年１１月１９日 月曜日 午前１０時３５分

Yamaha F70 Specifications

Engine Specifications

engine type	16-Valve, SOHC In-Line Four Cylinder
displacement	996 cc
bore x stroke	65 x 75 mm
compression ratio	9.4:1

Power

full throttle rpm range	5300 ~ 6300
horsepower rating	70 hp at 5800 rpm
alternator output	17 Amp

Fuel and Lubrication

recommended fuel	Regular Unleaded (Minimum Pump Octane 87)
ethanol blend limit	10% Maximum
engine oil capacity	2.1 L with filter

Weight and Dimensions

weight	118 kg
degree of trim	-4° through +16°
degree of tilt	65°
