10. SPECIFICATIONS
Specification Table
Product Name
Precision Oven
Model Name
DF412
DF612
DH412
DH612
System
Forced air circulation and ventilation
Working ambient
temperature range
5°C～35°C
Power supply
Single-phase
220V AC 12.5A
Single-phase
220V AC 17.5A
Single-phase
220V AC 15.5A
Singe-phase
220V AC 21.5A
50/60Hz, voltage variation tolerance: ±10％
Performance
*1
Temperature Control
Range
Room temp. +15°C～260°C
Room temp. +15°C～360°C
Temperature control
precision
±0.1°C (at 260°C) JTM K05
±0.2°C (at 360°C) JTM K05
Temperature variance
*2
±0.5°C (at 260°C) JIS C60068
±1.0°C (at 360°C) JIS C60068
Temperature
distribution precision
±1.5°C (at 260°C) JTM K05
±2.5°C (at 360°C) JTM K05
Temperature gradient
10°C (at 260°C) JIS C60068
12°C (at 360°C) JIS C60068
Temperature build
time (to max temp)
Approx. 40min.
Approx. 50min.
Configuration
Exterior
Chrome-free electro-galvanized steel sheet metal
Chemical-proof baked-on finish
Chamber
Stainless steel sheet metal
Insulation Material
Glass wool
Door
Single swivel (left swing)
Heater
Stainless steel tube heater with metal cooling fins
Heater capacity
2.1kW
3.0kW
2.7kW
3.75kW
Fan (motor)
Stainless steel axial fan (capacitor motor 20W)
Cable port
I.D. :φ33mm (rear panel)
Exhaust port
Automatic exhaust damper I.D. φ80mm (rear panel)
Control
Devices
& Functions
Type
Model V (5) controller
Temperature control
system
PID, Z control
Temperature setting
system
Digital setting with ▲/▼ keys.
Temperature display
system
Upper display (Chamber): Green 4-digit LED Digital Display (Resolution: 1°C)
Lower display: Orange 5-digit LED Digital Display (Resolution: 1°C)
Other displays
LEDs indicating temperature patterns for heating/stablization/cooling
Timer
Configurable from 1 minute to 99 hours 59 minutes: timer operation
24 hour time system: clock operation
Operation modes
Fixed temperature operation
Programmed operation（Maximum 99 steps or 99 patterns, with repeat
operation function）
Timer or clock operation function (Fixed temperature operation w/ auto
start/auto stop/quick auto stop, programmed operation auto start）
