Yealink SIP-T19P User Manual

User Guide for the SIP-T19P IP Phone
78
You can use call pickup to answer someone else’s incoming call on the phone. The
SIP-T19P IP phone supports directed call pickup and group call pickup. Directed call
pickup is used for picking up a call that is ringing at a specific phone number. Group call
pickup is used for picking up a call that is ringing at any phone number in the group. The
pickup group should be predefined, contact your system administrator for more
information.
You can pick up an incoming call by using the DPickup/GPickup soft key. To use call
pickup, you need to configure the call pickup code beforehand on a global or per-line
basis via web user interface.
Note
Directed Call Pickup
To enable the directed call pickup via web user interface:
1. Click on Features->Call Pickup.
2. Select Enabled from the pull-down list of Directed Call Pickup.
3. Click Confirm to accept the change.
To configure the directed call pickup code on a global basis via web user interface:
1. Click on Features->Call Pickup.
If there are many incoming calls at the same time, pressing the GPickup soft key on the
phone will pick up the call that rings first.

Yealink SIP-T19P Specifications

General

Speakerphone	Yes
Voice codecs	CNG, G.711, G.723, G.726, G.729ab, VAD
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Front camera	No
Display resolution	132 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Security algorithms	802.1x RADIUS, AES, HTTPS
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3u
Supported network protocols	IPv6
Ethernet LAN (RJ-45) ports	2
Number of handles included	- pc(s)
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	188 mm
Width	185 mm
Height	143 mm
