Yealink SIP-T41S User Manual

Customizing Your Phone
69
If Common is selected, this account will use the ring tone selected for the phone.
4. (Optional.) Press the Volume key to adjust the ringer volume.
5. Press Save.
A ring tone for the account is configurable via web user interface at the path
Account->Basic->Ring Type.
Uploading a Custom Ring Tone
The ring tone file must meet the following:
Phone Model
Format
Single File Size
Note
SIP-T48S/T46S/T42S/T41S
.wav
<=8MB
2MB of space should be
reserved for the phone
SIP-T48G/T46G
.wav
<=8MB
2.4MB of space should be
reserved for the phone)
SIP-T42G/T41P/T40P/T40G
.wav
<=100KB
5KB of space should be
reserved for the phone
Downloaded from ManualsNet.com search engine

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
