WhatDoYouWanttoConfigure?
1. Measurement Source
You can assign DC voltages, thermocouples, RTDs, and on/off signals based on contacts
and voltages to channels to take measurements. The measurement section is modular, so it
can be expanded as necessary.
Input signals are sampled at the scan interval and converted to measured values through
A/D conversion.
SettingMeasurementConditions(Settingmenu:Measurementsettings)
Item Reference
Setting the scan interval →page 1-90
Setting the operation mode of a module (AI module: 2ch mode/10ch mode, DI
module: normal/remote)
→page 1-91
Setting the A/D integration time of an AI module (analog input module) →page 1-92
Setting how to detect over-range values →page 1-90
Setting the burnout criteria →page 1-93
2. Configuring Measurement Channels
You can set measurement conditions for each channel based on the input. You can calculate
the difference between two input values or convert input values to measurement values with
units that suit your purpose.
Alarms can be generated when measured data exceeds or goes below specified values.
Information that indicates alarm occurrence can be shown on the screen. Digital output
channels (DO channels) can be used to transmit relay contact signals.
You can change channel colors and assign tags to channels.
ConfiguringAnalogInputChannels(Settingmenu:AIchannelsettings,AI(mA)
channel)
Source module: Analog input module (GX90XA)
Setting the Range
Item Reference
Input range (type, range, span lower, span upper)
→page 1-13
Performing input calculation (delta, linear scaling, square root)
Taking the moving average of input values (suppressing noise)
Setting the reference junction compensation mode (internal, external)
Setting burnout detection
Adding bias to input values
Setting Alarms
Item Reference
Setting alarms (type, value, hysteresis, logging, output, alarm delay) →page 1-19
Setting the Display
Item Reference
Setting channel tags (characters, No.)
→page 1-23
Setting display colors
Dividing display areas to prevent waveform overlap (setting zones)
Setting the scale display position and divisions
Setting the base position and divisions of the bar graph display
Enabling the partial expanded display →page 1-23
→page 1-85
Displaying the color scale band (band area (in, out), color)
→page 1-23Displaying alarm point marks (mark kind, alarm mark color)
Displaying on/off (1/0) signals with characters (when the range type is DI)
Chapter 1 Configuring the GX/GP
