YOKOGAWA GX60 User Manual

1-197
IM 04L51B01-01EN
Configuring the GX/GP
1
2
3
4
5
App
Index
1.22.2 Saving a Scale Image
Path
GX/GP: MENU key > Browse tab > Save load > Menu Save settings > Scale image
Description
Setup Item Selectable Range or Options Default Value
Media kind SD, USB
1
File name — —
1 See page 1-152 in section 1.20.1, “Loading Setting Parameters”
Media kind
Set the save destination medium.
File name
Set the file name.
Setup Item Selectable Range or Options Default Value
Batch group number GX10/GP10/GX20-1/GP20-1: 1 to 6
GX20-2/GP20-2: 1 to 12
1
Group number GX20-1/GP20-1: 1 to 50
GX20-2/GP20-2: 1 to 60
GX10/GP10: 1 to 30
1
Data — —
Batch group number
Set the batch group number to save the scale image to.
Group number
Set the group number to save the scale image to.
Data
Displays the presence or absence of the specified file.
Procedure
Whenthemulti-batchfunction(/BToption)isnotavailableordisabled
1 Tap Media kind, set the medium.
2 Tap File name, set the file name.
3 Tap Group number, set the gropu number.
4 Tap Execute.
The scale image is saved.
5 Tap Exit.
The GX/GP returns to the original screen.
Operation complete
1.22 Saving Setting Parameters
