York LX series Installation Manual

17
Auxiliary Heat Ratings
Auxiliary Heat Electrical Data
Electrical Data
Model
KW
Stages
BTU/HR
Min CFM
208V 230V 208V 230V 024 036 048 - 072
EAM(H)5* 3.6 4.8 1 12,300 16,300 450 ●●
EAM(H)8* 5.7 7.6 2 19,400 25,900 550 ●●
EAM(H)10* 7.2 9.6 2 24,600 32,700 650 ●
EAL(H)10* 7.2 9.6 2 24,600 32,700 1100 ●
EAL(H)15* 10.8 14.4 2 36,900 49,100 1250 ●
EAL(H)20* 14.4 19.2 2 49,200 65,500 1500 ●
Order the “H” part number when installed on horizontal units 6/9/2014
Air flow level for auxiliary heat (Aux) must be equal to or above the minimum CFM in this table
Model
Supply
Circuit
Heater Amps Min Circuit Amp Fuse (USA) Fuse (CAN) CKT BRK
208 V 240 V 208 V 240 V 208 V 240 V 208 V 240 V 208 V 240 V
EAM(H)5* Single 17.3 20.0 26.7 30.0 30 30 30 30 30 30
EAM(H)8* Single 27.5 31.7 39.3 44.6 40 45 40 45 40 45
EAM(H)10* Single 34.7 40.0 48.3 55.0 50 60 50 60 50 60
EAL(H)10* Single 34.7 40.0 53.3 60.0 60 60 60 60 60 60
EAL(H)15*
Single 52.0 60.0 75.0 85.0 80 90 80 90 70 100
L1/L2 34.7 40.0 53.3 60.0 60 60 60 60 60 60
L3/L4 17.3 20.0 21.7 25.0 25 25 25 25 20 30
EAL(H)20*
Single 69.3 80.0 96.7 110.0 100 110 100 110 100 100
L1/L2 34.7 40.0 53.3 60.0 60 60 60 60 60 60
L3/L4 34.7 40.0 43.3 50.0 45 50 45 50 40 50
All heaters rated single phase 60 cycle and include unit fan load 3/10/14
All fuses type “D” time delay (or HACR circuit breaker in USA)
Supply wire size to be determined by local codes
Dual Capacity Unit with 5 Speed ECM Motor
Model
Rated
Voltage
Voltage
Min/Max
Compressor
HWG
Pump
FLA
Ext
Loop
FLA
Blower
Motor
FLA
Total
Unit
FLA
Min
Circ
Amp
Max
Fuse/
HACR
MCC RLA LRA LRA**
024 208-230/60/1 187/253 18.2 11.6 58.3 21.0 0.4 5.4 4.1 21.5 24.5 35
036 208-230/60/1 187/253 23.8 15.2 83.0 30.0 0.4 5.4 4.1 25.1 28.9 40
048 208-230/60/1 187/253 33.0 21.1 104.0 37.0 0.4 5.4 7.6 34.5 39.8 60
060 208-230/60/1 187/253 42.3 27.1 152.9 54.0 0.4 5.4 7.6 40.5 47.2 70
072 208-230/60/1 187/253 46.3 29.6 179.2 63.0 0.4 5.4 7.6 43.0 50.4 80
**With optional IntelliStart 6/9/14
Rated Voltage of 208/230/60/1
HACR circuit breaker in USA only
All fuses Class RK-5
LX SERIES INSTALLATION MANUAL
