York LX series Installation Manual

19
TOP
TOP
3 SERIES VERTICAL SUBMITTAL DATA
FRONT
LEFT RETURN
RIGHT RETURN
A
B
B
C
C
D
E
H
F
G
S
T
S
T
R R
Q Q
N
L
O M
O
L
N
P
I
J
K
1.90 4.8
1.90 4.8
2 ft [61 cm]
Primary Service Access
2 ft [61 cm] Alternate
Service Access. Right Return
Opposite Side
Vertical
Top Flow
Model
Overall Cabinet Water Connections
Electrical
Connections
Discharge Connection Return Connection
I
3/4”
cond
J
1/2”
cond
K
1/2”
cond
Duct Flange Installed Return Duct Flanges
ABCDEFGH
Loop
Water
FPT
HWG
Sweat
(I.D.)
LM N O PQ R S T
Width Depth Height
Loop
In
Loop
Out
HWG
In
HWG
Out
Cond-
ensate
Power
Supply
Ext
Pump
Low
Votage
Supply
Width
Supply
Depth
Return
Depth
Return
Height
024
in. 22.5 26.5 39.4 2.3 5.3 13.4 16.4 9.6
1”
Swivel
1/2”
female
8.9 11.4 13.7 6.3 0.7 14.0 14.0 2.7 2.3 22.0 18.0 1.8
cm. 57.2 67.3 100.1 5.8 13.5 34.0 41.7 24.4 22.6 29.0 34.8 16.0 1.8 35.6 35.6 6.9 5.8 55.9 45.7 4.6
036
in. 22.5 26.5 44.5 2.0 7.0 13.5 16.5 10.2
1”
Swivel
1/2”
female
9.5 12.1 14.3 6.1 0.8 14.0 14.0 4.4 2.4 22.0 22.0 2.0
cm. 57.2 67.3 113.0 5.1 17.8 34.3 41.9 25.9 24.1 30.7 36.3 15.5 2.0 35.6 35.6 11.2 6.1 55.9 55.9 5.1
048-
060
in. 25.6 31.6 50.4 2.3 7.3 15.9 18.9 10.6
1”
Swivel
1/2”
female
9.8 12.3 14.6 6.9 1.1 18.0 18.0 3.8 1.7 28.0 26.0 1.7
cm. 65.0 80.3 128.0 5.8 18.5 40.4 48.0 26.9 24.9 31.2 37.1 17.5 2.8 45.7 45.7 9.7 4.3 71.1 66.0 4.3
072
in. 25.6 31.6 54.4 2.3 7.3 15.9 18.9 10.6
1”
Swivel
1/2”
female
9.8 12.3 14.6 6.9 1.1 18.0 18.0 3.8 1.7 28.1 30.0 2.2
cm. 65.0 80.3 138.2 5.8 18.5 40.4 48.0 26.9 24.9 31.2 37.1 17.5 2.8 45.7 45.7 9.7 4.3 71.4 76.2 5.6
Condensate is 3/4” PVC female glue socket and is switchable from side to front 7/17/14
Unit shipped with 1” [25.4mm] return duct flanges and are suitable for duct connection.
Discharge flange is field installed and extends 1” [25.4mm] from cabinet
Water connections extend 1.2” [30.5mm] beyond front of cabinet.
The optional 1” filter rack (not shown) has the same return opening connection size as the duct flanges shown in the drawing. The filter rack extends 2.25”(57.1 mm)
from the unit.
The optional 1” filter rack is suitable for duct connection.
The optional filter rails (not shown) extend 1.25” (31.75 mm) from cabinet.
Vertical Dimensional Data
LX SERIES INSTALLATION MANUAL
