Heat of Extraction/Rejection
Model GPM
Heat of Extraction (kBtuh) Heat of Rejection (kBtuh)
30°F 50°F 70°F 90°F 30°F 50°F 70°F 90°F 110°F
024
Part Load
3.0 12.6 16.1 20.1 21.1 20.8 20.1
5.0 9.2 13.2 17.4 21.4 20.3 21.2 20.9 20.1 19.4
7.0 10.0 13.9 17.8 21.4 20.5 21.5 21.1 20.3 19.5
Full Load
4.0 17.7 21.9 25.8 29.8 29.2 27.9
6.0 13.5 18.4 23.1 27.5 28.7 30.0 29.5 28.4 27.0
8.0 13.9 18.9 23.8 28.5 28.9 30.2 29.7 28.5 27.1
036
Part Load
4.0 18.7 24.7 31.1 34.0 32.9 31.7
6.0 13.4 19.5 26.1 33.1 29.7 34.2 33.0 31.8 30.1
8.0 14.5 20.6 26.8 33.1 29.9 34.6 33.4 32.1 30.4
Full Load
5.0 26.6 33.1 39.2 45.3 45.0 42.9
7.0 20.5 27.7 34.9 41.8 40.3 45.7 45.5 43.7 41.3
9.0 21.0 28.4 36.0 43.3 40.6 46.0 45.8 43.9 41.5
048
Part Load
5.0 23.5 29.1 34.6 45.0 44.9 43.1
8.0 18.9 25.9 32.1 38.5 39.3 45.1 44.7 42.5 40.7
11.0 19.5 26.9 33.8 41.0 39.6 45.1 45.0 43.2 41.7
Full Load
6.0 31.6 39.2 46.3 63.2 63.2 60.6
9.0 25.7 34.9 43.4 51.7 55.8 62.9 62.6 59.7 56.4
12.0 26.6 36.2 45.8 55.1 56.1 62.7 62.9 60.7 57.7
060
Part Load
6.0 31.3 39.5 47.1 56.3 54.8 52.5
10.0 21.5 31.6 41.2 50.8 46.2 56.1 54.8 52.8 49.0
14.0 22.6 32.8 42.1 50.9 46.5 56.1 55.0 53.1 49.3
Full Load
8.0 39.7 51.8 63.6 73.1 74.3 72.9
12.0 30.7 42.6 54.2 64.7 63.4 73.5 74.7 73.1 69.4
16.0 31.0 43.5 55.9 67.4 63.8 73.9 75.0 73.5 69.5
072
Part Load
10.0 40.7 52.2 63.1 67.9 68.0 63.3
13.0 28.5 41.0 54.5 68.1 55.8 67.7 67.9 63.5 60.6
16.0 30.2 42.7 55.5 68.1 56.2 67.6 68.2 63.8 61.0
Full Load
12.0 51.0 66.0 80.7 83.1 87.8 84.5
15.0 40.2 54.5 68.8 81.9 69.5 83.4 88.1 84.8 82.1
18.0 40.7 55.6 71.0 85.3 69.9 83.9 88.7 85.2 82.3
Note: operation not recommended in shaded areas. 7/21/14
