505428-YTG-V-0417
10 Johnson Controls Unitary Products
PC090 - 180 and PD180 - 240 Physical Data
Component
Models
PC090 PC120 PC180 PD180 PD240
Nominal Tonnage 7.5 10 15 15 20
REFRIGERANT
Refrigerant type R-410A R-410A R-410A R-410A R-410A
Holding charge (lb)
1
1.0 1.0 1.0 1.0 1.0
Operating Charge (lb)
2
System #1 23.9 31.75 54.0 27.0 34.0
System #2 --- --- --- 27.0 34.0
DIMENSIONS (inches)
Length 59.1 59.1 59.1 59.1 59.1
Width 31.9 31.9 64.1 64.1 64.1
Height 44.5 50.0 44.5 44.5 50.0
WEIGHTS (lb)
Shipping 421 543 947 921 1090
Operating 430 574 968 942 1126
COMPRESSORS
3
Type Single Scroll Tandem Scroll Tandem Scroll Single Scroll Single Scroll
Quantity 1 1 1 2 2
Cooling
Nominal Capacity (Tons)
System #1 7.5 10 15 7.5 10
System #2 --- --- --- 7.5 10
Capacity Stages
System #112211
System #2 --- --- --- 1 1
Heating
Nominal Capacity (Tons) System #1 & #2 7.5 10 15 15 20
Capacity Stages System #1 & #2 1 1 1 1 1
SYSTEM DATA
No. Refrigeration Circuits 1 1 1 2 2
Suction Line OD (in.) 1 1/8 1 3/8 1 5/8 1 3/8 1 3/8
Liquid Line OD (in.) 5/8 7/8 7/8 5/8 5/8
OUTDOOR COIL DATA
Face area (Sq. Ft.) 23.8 29.0 47.5 47.5 58.1
Rows 22222
Fins per inch 20 20 20 20 20
Tube diameter (in./MM) 0.38 / 10 0.38 / 10 0.38 / 10 0.38 / 10 0.38 / 10
Circuitry Type Interlaced Interlaced Interlaced Interlaced Interlaced
Refrigerant Control TXV TXV TXV TXV TXV
CONDENSER FAN DATA
No. Fans / Diameter (in.) 2/24 2/24 4/24 4/24 4/24
Type Axial Axial Axial Axial Axial
Drive type Direct Direct Direct Direct Direct
No. speeds 1 1 1 1 1
Number of motors
System #122422
System #2 --- --- --- 2 2
Motor HP (ea.) 1/3 3/4 1/3 1/3 3/4
Rotation
4
CW CW CW CW CW
RPM 850 1100 850 850 1100
Nominal CFM
System #1 7500 9800 15000 7500 9800
System #2 --- --- --- 7500 9800
1
Holding Charge is the amount in the unit as shipped from the factory.
2
Includes matched evaporator unit with 25 ft of piping.
3
All compressors include crankcase heaters.
4
When viewing the shaft end of the motor.
