York R-410A Technical Guide

505428-YTG-V-0417
12 Johnson Controls Unitary Products
NL090 - 240 and NM120 - 240 Indoor Unit Physical Data
Component
Models
NL090 NL120 NM120 NL180 NM180 NL240 NM240
Nominal Tonnage 7 1/2101015152020
DIMENSIONS (inches)
Length
56.0 56.0 56.0 74.5 74.5 98.5 98.5
Width
30.0 30.0 30.0 33.0 33.0 30.0 30.0
Height
65.0 65.0 65.0 75.0 75.0 65.0 65.0
WEIGHTS (lb)
Unit Shipping Standard Motor & Drive 542 586 588 794 794 932 932
Unit Shipping High Static Motor & Drive 549 597 599 850 850 963 963
Unit Operating With Standard Motor& Drive 516 563 565 762 762 897 897
Unit Operating With High Static Motor & Drive 523 574 576 788 788 928 928
INDOOR BLOWER (Forward Curve)
Diameter x Width 12 x 12 15 x 15 15 x 15 18 x 18 18 x 18 15 x 15 15 x 15
Quantity 1 1 1 1 1 2 2
INDOOR COIL
Face area (Sq. Ft.) 10.6 10.6 10.6 18.3 18.3 20.0 20.0
Rows 3444444
Fins per inch 15 15 15 15 15 15 15
Tube diameter 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced Interlaced Interlaced Interlaced
Refrigerant Control TXV TXV TXV TXV TXV TXV TXV
SYSTEM DATA
No. Refrigeration Circuits 1 1 2 1 2 1 2
Suction Line OD (in.) 1 1/8 1 3/8 1 1/8 1 5/8 1 3/8 1 5/8 1 3/8
Liquid Line OD (in.) 5/8 7/8 5/8 7/8 5/8 7/8 7/8
FILTERS
Size and Quantity Per
Model (In.)
16 x 25 x 2 4 4 4 --- --- 8 8
20 x 24 x 2 --- --- --- 6 6 --- ---
FACE AREA (SQ. FT.) 11.1 11.1 11.1 20.0 20.0 22.2 22.2
Size and Quantity Per
Model (In.)
16 x 25 x 4 4 4 4 --- --- 8 8
20 x 24 x 4 --- --- --- 6 6 --- ---
FACE AREA (SQ. FT.) 11.1 11.1 11.1 18.0 18.0 22.2 22.2
